Product / UTG
Overview
- For shut-off and balancing of air intake and exhaust ducts
- Shock tested
- A closed damper fulfils the requirement of leakage class up to class 3 (EN1751:2014). Details available from Halton
- Classification of casing leakage (EN 1751:2014) class B
- The outer frame of galvanised, painted or stainless steel. Blades of galvanised or stainless steel with double sheet construction, and silicon sealings. Maintenance-free stainless steel bearings and shafts
- Electrical, pneumatical or manual operation system available
- UTG dampers can be supplied with connection pieces for round duct
- The maximum duct pressure for damper construction is 5000 Pa. The maximum air velocity is 15 m/s. In case of high duct pressure, contact Halton Marine for finding the most suitable solution
- Temperature operation range up to +100 °C, optionally up to +180 °C
- Available as ATEX certified
- SIL 2 safety assessment certificate available for the damper on specific terms
Specification
Halton UTG dampers are used to shut-off and balance airflow rates in high pressure ductworks. Dampers meet international standards for rectangular and round ducts. In the open position, the blades face the direction of flow and do not cause a significant pressure loss. The UTG is used as a shut-off, gas and balancing damper in applications where tightness and reliability are important.
Dimensions and Material Thickness
UTG shut-off, gas and balancing dampers meet international standards for both rectangular (width B 100-1200 mm and height H 100-1600 mm, 1 mm division) and circular ducts (Ø100-1250 mm). Non-standard dimensions are available on request. Standard flange width 27 mm. Flanges and drilling also available according to ISO 15138 standards. Modular construction sizes available up to 2400X3200 mm. Frame thicknesses from 3 mm to 10 mm. Standard frame thickness is 3 mm. Blades are made of two sheets, each of them being 1 mm thick (sandwich design).
Actuator effect on dimensions
ACTUATOR | DIMENSIONS | ||
R | A | ||
Manual | Handle | 95 | H |
Electrical | BF230, BF24, BF120 | 100 | H<300 = 300, H>300 =H |
Pneumatic PNR | Pneumatic rotating actuator AT100 | 170 | H<300 = 300, H>300 =H |
Pneumatic PNR | Pneumatic rotating actuator AT200 | 190 | H<350 = 350, H>350 =H |
The above table contains only some examples of actuators and their effect on dimensions.
UTG, general drawings
With circular connections
UTG, top
UTG circular, with connection flanges
DAMPER HEIGHT | TOTAL DEPTH WITH BLADES OPEN |
< 350 mm | 210 mm |
> 350 mm | 240 mm |
Material and Finishing
PART | MATERIAL | FINISHING |
Frame | Carbon steel | Painted or galvanized |
Frame | Stainless steel EN 1.4301 (AISI304), EN 1.4404 (AISI316L), EN 1.4432 (AISI316L) | – |
Blades | Steel | Galvanized |
Blades | Stainless steel EN 1.4301 (AISI304), EN 1.4404 (AISI316L), EN 1.4432 (AISI316L) | – |
Maintenance-free bearings and shafts |
Stainless steel EN 1.4404 (AISI316L) | – |
Shafts | Stainless seel EN 1.4404 (AISI316L) | – |
Standard frame material thickness 3 mm.
Product Models
Halton UTG is available with following actuators:
- UTG-EL: Electrical spring return actuator; standard actuators being 24 VAC/DC or 230 VAC or 120 VAC. Depending on the choice of actuator, the actuator might contain built-in open-closed limit switches. A wide range of Ex actuators available, including a one second closing time function as an option (for limited sizes).
- UTG-PNR: Pneumatic rotating actuator
- UTG-MAN: Manual handle
HSO: Halton Smart Override function for HVAC damper black-start available for PNR and EL models. With automatic reset function when power and/or pneumatic air supply is reinstated.
A wide range of accessories available.
Weights
Weights of standard Halton UTG dampers (kg)
Without an actuator
HEIGHT (mm) |
B / WIDTH (mm) | |||||||||||
100 | 200 | 300 | 400 | 500 | 600 | 700 | 800 | 900 | 1000 | 1100 | 1200 | |
100 | 4 | 6 | 7 | 9 | 10 | 12 | 13 | 15 | 16 | 17 | 19 | 20 |
200 | 6 | 8 | 9 | 11 | 13 | 14 | 16 | 17 | 19 | 21 | 22 | 24 |
300 | 8 | 10 | 12 | 14 | 15 | 17 | 19 | 21 | 22 | 24 | 26 | 28 |
400 | 10 | 12 | 14 | 16 | 18 | 20 | 22 | 23 | 25 | 27 | 29 | 31 |
500 | 13 | 15 | 17 | 19 | 21 | 23 | 25 | 28 | 30 | 32 | 34 | 36 |
600 | 15 | 17 | 19 | 21 | 24 | 26 | 28 | 30 | 33 | 35 | 37 | 39 |
700 | 17 | 20 | 22 | 25 | 27 | 29 | 32 | 34 | 37 | 39 | 42 | 44 |
800 | 19 | 22 | 24 | 27 | 29 | 32 | 35 | 37 | 40 | 43 | 45 | 48 |
900 | 21 | 24 | 27 | 30 | 33 | 36 | 38 | 41 | 44 | 47 | 50 | 53 |
1000 | 23 | 26 | 29 | 32 | 35 | 38 | 41 | 44 | 47 | 50 | 53 | 56 |
1100 | 26 | 29 | 32 | 35 | 38 | 42 | 45 | 48 | 51 | 55 | 58 | 61 |
1200 | 27 | 31 | 34 | 37 | 41 | 44 | 48 | 51 | 54 | 58 | 61 | 64 |
1300 | 30 | 33 | 37 | 41 | 44 | 48 | 51 | 55 | 58 | 62 | 66 | 69 |
1400 | 32 | 35 | 39 | 43 | 47 | 50 | 54 | 58 | 61 | 65 | 69 | 73 |
1500 | 34 | 38 | 42 | 46 | 50 | 54 | 58 | 62 | 66 | 70 | 74 | 77 |
1600 | 36 | 40 | 44 | 48 | 52 | 56 | 60 | 65 | 69 | 73 | 77 | 81 |
D2 ØD (mm) |
WEIGHT kg |
100 | 7 |
125 | 8 |
160 | 11 |
200 | 12 |
250 | 17 |
315 | 19 |
400 | 26 |
500 | 34 |
630 | 44 |
800 | 59 |
1000 | 80 |
1250 | 110 |
Examples of actuator weights: UTG-EL BF230 +3,2 kg, ExMax/Redmax +3,5 kg, CSQP +3 kg, UTG-PNR AT100 +2,1 kg, AT100 as AISI316 4,4 kg, AT50 1,2 kg, UTG-MAN+ 1 kg. Control enclosure+4 kg.
Product Code
(S)=Shape of Connection
(A) Circular on one side
(C ) Circular on two sides
(R) Rectangular
(W)=Width
100-1200
(H)=Height
100-1600
(D)=Diameter
100-1250
(EX)=Atex Certification
(NA) No
(X1) ATEX Certified damper [please fill]
(SF)=Flange Option
(H0) Eurovent flange in circular connections
(H1) Eurovent flange + loose flange in circular connections
(HA) Eurovent flanges
(HB) Eurovent flanges + counter flanges (2 sides)
(HC) Eurovent flanges + counter flange (1 side)
(N0) ISO15138 flange drilling in circular connection
(N1) ISO15138 flange drilling + Loose flange in circular connection
(NA) Circular connections without flanges
(NR) ISO15138 flange drilling
(MA)=Material Blades
(AS) Stainless steel 1 mm EN1.4404
(CS) Carbon steel 1 mm
(LS) Stainless steel 1 mm EN1.4432
(SS) Stainless steel 1 mm EN1.4301
(FM)=Frame Material
(A3) Stainless steel 3 mm EN1.4404
(A5) Stainless steel 5 mm EN1.4404
(C3) Carbon steel 3 mm
(C5) Carbon steel 5 mm
(L3) Stainless steel 3 mm EN1.4432
(L5) Stainless steel 5 mm EN1.4432
(S3) Stainless steel 3 mm EN1.4301
(S5) Stainless steel 5 mm EN1.4301
(FI)=Finishing
(HG) Hot galvanized
(NA) Acid treatment
(PN) Standard painting grey RAL7001
(PX) Special Painting C5-M ISO12944
(BR)=Bearing Material
(BR) Bronze JM5
(MS) Brass
(AS) Stainless steel EN1.4404
(RE)=Actuator
(E1) Electric – Belimo, BF24-2-HL
(E3) Electric – Belimo, BF230-2-HL
(E7) Electric – Belimo, BF120-HL
(I1) InMax – Schischek, 15-SF
(I2) InMax – Schischek, 15-SF VAS
(I3) InMax – Schischek, 15-SF1 VAS
(I4) InMax – Schischek, 8-SF-1
(I6) InMax – Schischek, 15-SF-1
(I9) InMax – Schischek, 5.10-SF
(I10) InMax – Schischek, 5.10-SF VAS
(I11) InMax – Schischek, 8-SF-1 VAS
(P0) Pneumatic – Air Torque, AT101, Aluminium
(P3) Pneumatic – Air Torque, AT104, AISI316
(Q1) Pneumatic – Air Torque, AT201, Aluminium
(Q2) Pneumatic – Air Torque, AT204, AISI316
(Z2) Electric (EX) – Schischek, ExMax 15-SF
(Z3) Electric (EX) – Schischek, ExMax 5-10SF
(Z4) Electric (EX), Schischek, ExMax 15-SF VAS
(Z5) Electric (EX) – Schischek, ExMax 15-SF1 VAS
(Z6) Electric (EX) – Schischek, ExMax 8-SF1
(Z7) Electric (EX) – Schischek, ExMax 15-SF1
(Z10) Electric (EX) – Schischek, ExMax 5.10-SF VAS
(Z11) Electric (EX) – Schischek, ExMax 8-SF1 VAS
(C1) Electric – Elodrive, CSQP-05A1E 24V
(C2) Electric – Elodrive, CSQP-05A2E 120/230V
(C3) Electric – Elodrive, CSQP-10A1E 24V
(C4) Electric – Elodrive, CSQP-10A2E 120/230V
(C5) Electric – Elodrive, CSQP-15A1E 24V – Blocked
(C6) Electric – Elodrive, CSQP-15A2E 120/230V – Blocked
(A7) Electric – Belimo, SF24A-S2
(A9) Electric – Belimo, SF230A-S2
(MA) Manual handle
(NA) Not Assigned
(AC)=Accessories
(BC) Belimo Casing
(E1) Junction box – Ensto, Plastic, IP66 & 67
(E2) EX junction box – Cooper, GRP, IP66, T6
(E5) Cable connectors – Wieland & Hensel (Shutoff)
(L2) Limit switch 2 pcs – Bernstein, Plastic, IP66, Mechanical
(L4) EX Limit switch 2 pcs – Bartec, Plastic, IP66, Mechanical
(L5) EX Limit switch 4 pcs – Bartec, Plastic, IP66, Mechanical
(L6) EX Magnetic switch 2 pcs – Elobau, AISI6118, Magnetic
(L7) EX Magnetic switch 4 pcs – Elobau, AISI6118, Magnetic
(L8) EX Magnetic switch 2 pcs – Pepperl & Fuchs, AISI303, Inductive
(L9) EX Magnetic switch 4 pcs – Pepperl & Fuchs, AISI303, Inductive
(M1) Solenoid valve – SMC, Aluminium, 24 VDC
(M2) Solenoid valve – SMC, Aluminium, 230 VAC
(M3) EX solenoid valve – ASCO, Brass, 24 VDC
(M4) EX solenoid valve – ASCO, Brass, 230 VAC
(M5) EX solenoid valve – Bifold, AISI316, 24 VDC
(P1) Manual pneumatic valve – SMC, Aluminium
(P2) Manual pneumatic valve – Bifold, AISI316
(S3) Limit switch open/Close – Belimo, SN2, Mechanical
(SC) Cover box – Stainless steel
(ST) Pneumatic tubing & fittings – AISI316
(ED) Manual over-ride handle – Halton DOT or HV-SKU
(O1) Smart override handle – Halton, HSO Schischek
(O2) Smart override handle – Halton, HSO Pneumatic
Code example
UTG/R-500-500,SF=HA,MA=CS,FM=C3,FI=HG,BM=AS,RE=A9,ZT=N,AC=E1
