Halton APS – Jet air diffuser

Overview

• Specially designed for large enclosures
• Long throw pattern with low velocity reduction
• Auto-balancing of the duct work due to units high pressure drop
• Directional air pattern; maximum deflection angle of 30° in all directions
• Circular duct connection with rubber gasket
• Corrosion resistant aluminium material
• Architectural design, no visible screws

Quick selection

Dimensions

Material

Function

Supply air is supplied to the space at a high velocity.
The supply air mixes efficiently with the room air, with a high induction effect.
The supply air jet can be directed at an angle of 30° when the angle of roll is 360°.

Installation

Code  Description
1.  Frame
2.  Fixing screws
3.  Cover plate

The Halton APS jet nozzle diffuser is fastened to the wall with screws.
Screw the fixing screws into the pre-drilled holes in the front panel.
Install the cover plate on the frame and screw the headless screw located on the cover plate.

Note:
When a connection to the duct is required, an additional part can be supplied (Flange for Halton APL).

Servicing

Remove the cover plate by unscrewing the headless screw.
Remove the diffuser by unscrewing the visible fixing screws.

Clean the parts by wiping them with a damp cloth.

Push the diffuser back into place and screw in the fixing screws.
Push the cover plate and screw it.

Specification

The supply air jet is directional in an angle of 30°, when the angle of roll is 360°.

The  diffuser ensures the auto-balancing of the network due to its high pressure drop.

The  diffuser ensures a good diffusion for large enclosure.

The jet nozzle is made of heavy aluminium.

The the diffuser is either anodised, painted (white,RAL 9003) or polished mill as standard.

The diffuser includes a sealing gasket.

The diffuser should has no visible screws.

Directional adjustment is accurate, accomplished without the use of special tools, and ise able to provide 70° of global rotation with minimal restriction of movement.
