UPT – Unipoint services distribution unit (CE)

Internal services included

CE Marked (UKCA pending) – Designed for use in commercial kitchens, the UPT Unipoint range of Service Distribution Units (SDU) provides an efficient and economical layout for services distribution (gas, hot water, cold water, chilled water, compressed air, electrical power, fire and safety control, steam supply, condensate return line etc).

Pre-assembled off site with all internal services, the Unipoint eliminates the co-ordination of other trades allowing minimal preparatory work in bringing main services to a ‘single point’ of connection for final ‘hook up’. In addition, it allows for future modifications to easily accommodate new utility requirements should appliances line ups change.

Overview

  • Custom made to suit each application. Available as either a wall-type unit (UPT-W) or island-type (UPT-I).
  • All internal pipework and technical services preassembled and tested off site. Fabrication only, can be provided if required.
  • Co-ordinated interface with ventilation products.
  • Fully accessible for easy cleaning and maintenance.
  • Total segregation of M&E services.
  • A wide range of optional extras.
  • More versatility and serviceability than conventional distribution methods.
  • Inbuilt’ flexibility allowing ease of additions/changes.
  • Dedicated and or multi-serviced risers to suit each application.
  • Custom made to suit each application.

Examples of configurations

A – Hood
B – Wall covering
C – Appliances power supplies
D – Side riser (electrical controls, fire suppression system, water filtration, fluids supply etc)
